Product Abstract:

SMD5050 RGB LED magic strip has up to hundreds of colorS, which can give you a visual feast


Product Description









Quick Details

  • Light Source: LED
  • Item Type: Light Strips
  • LED Light Source: SMD5050
  • Type: Flex LED Strips
  • Input Voltage(V): DC12V
  • Lamp Power: 7.2w/m
  • CRI (Ra>): 70
  • Color Temperature(CCT): RGB
  • Working Temperature(℃): -10 - 50
  • Working Lifetime(Hour): 25000
  • Lamp Body Material: FPC
  • Certification: CE,RoHS
  • Emitting Color: RGB
  • Place of Origin: China (Mainland)
  • Brand Name: KONNINE
  • Model Number: KN-5050MAG30R-10MM-12V
  • LED Item: SMD5050 RGB LED magic strip
  • LED Color: RGB
  • LED Source: LED SMD 5050
  • LED quantity: 30pcs/m
  • Input voltage: DC12V
  • Certificate: CE,RoHs
  • Warranty: 2 years
  • Life Span: 25,000hours

Packaging & Delivery

Packaging Details: Neutral package
Delivery Detail: 3~7 working days after confrimation

Specifications


SMD5050 RGB LED magic strip has up to hundreds of colorS, which can give you a visual feast



SMD5050 RGB LED magic strip

Description



This kind of constant-current LED Chase strip use 10mm width PCB Board instead 12mm. The price is better

 than old types. It has excellent white balance. We installed resistors on strip's signal line, which can protect leds

from sudden power-break.  What'sm ore, we have designed self-checking function for new type constant-cuurent

LED Chase strip. When connected to power, if all blue light is on, that means led strip is in good quality,



For this type of LED strip, we can make IP20,IP65,IP66,IP68 . Bur for our types, we can only make IP20 and IP67.



Features

1, Using SMD5050 as light source, which has higher quality and lumenous flux

2, various color for choose. Using controller to change color at random

3, Using FPC as materail, can be bended.

4, easy installation. We use 3M stick in the back to fix them

5, Wide application. It can be used to decorate car, ad board, sign board, cabinet and so on. It will give you a visual feast.



Products Specification



Item Value
LED Type SMD5050 RGB LED magic strip
Item No. KN-5050MAG30R-10MM-12V
LED Source SMD5050
LED quantity 30pcs/m
Power 7.2w/m
Voltage DC12V
Dimension 10x3x500mm
Beam Angle 120 °
Working Temperature -10~40°C
Color Temperature   RGB
 IP Rate IP20,IP65,IP66,IP68
Lifespan  25,000hours
Wanrranty  2 years
Certificate  CE, RoHs approved
 Package 5 meter/roll, packed in antistatic bag

Application

1. High shock / vibration resistant

2. Enviromental friendly: No mercury and others harmful materials

3. No flickery & RF interference, No buzzing noise, instant soft start and low heat

4. Widely used for office, bars, residential rooms, hotels, commercial buildings and so on

5. High Energy-efficient: Only 20% power consumption of halogen lamp and incandescent lamp
